Fassi F40B.21
Max. lifting capacity1.91 t
Max. radius5.05 m
Max. hook height6.3 m
Specifications
| Specification | Value |
|---|---|
| Lifting | |
| Max. lifting capacity | 1.91 t |
| Load moment | 3.9 t·m |
| Max. radius | 5.05 m |
| Max. hook height | 6.3 m |
| Dimensions and weight | |
| Length | 2,050 mm |
| Width | 585 mm |
| Height | 1,770 mm |
| Curb weight | 0.61 t |
About the model
The Fassi F40B.21 is a loader crane by Fassi with a maximum lifting capacity of 1.91 t.
Hook height 6.3 m, maximum radius 5.05 m.
