Grove · Truck cranes

Grove AP410

Max. lifting capacity7.9 t
Max. radius6.7 m
Max. hook height7.3 m

Specifications

Specifications Grove AP410
SpecificationValue
Lifting
Max. lifting capacity7.9 t
Max. radius6.7 m
Max. hook height7.3 m
Speeds
Travel speed27.4 km/h
Slewing speed1.5 rpm
Carrier and engine
Power57 kW
Dimensions and weight
Length4,532 mm
Width1,832 mm
Height2,829 mm
Total crane weight7.4 t
Tail swing radius1.07 m

Report a data error →

About the model

The Grove AP410 is a truck crane by Grove with a maximum lifting capacity of 7.9 t.

Hook height 7.3 m, maximum radius 6.7 m.

Engine output 57 kW.
