Grove · All-terrain cranes

Grove GMK5225

Max. lifting capacity204.1 t
Max. radius59.4 m
Max. hook height67 m

Specifications

Specifications Grove GMK5225
SpecificationValue
Lifting
Max. lifting capacity204.1 t
Max. radius59.4 m
Max. hook height67 m
Speeds
Travel speed85.1 km/h
Slewing speed1.3 rpm
Carrier and engine
Power405 kW
Dimensions and weight
Length15,792 mm
Width2,512 mm
Height4,002 mm
Total crane weight57.9 t
Tail swing radius3.78 m

Report a data error →

About the model

The Grove GMK5225 is an all-terrain crane by Grove with a maximum lifting capacity of 204.1 t.

Hook height 67 m, maximum radius 59.4 m.

Engine output 405 kW.
