Grove · All-terrain cranes
Grove GMK5240
Max. lifting capacity158.8 t
Max. radius54.9 m
Max. hook height60 m
Specifications
| Specification | Value |
|---|---|
| Lifting | |
| Max. lifting capacity | 158.8 t |
| Max. radius | 54.9 m |
| Max. hook height | 60 m |
| Speeds | |
| Travel speed | 82.1 km/h |
| Slewing speed | 1.7 rpm |
| Carrier and engine | |
| Power | 421 kW |
| Dimensions and weight | |
| Length | 15,630 mm |
| Width | 3,072 mm |
| Height | 3,956 mm |
| Total crane weight | 60.9 t |
| Tail swing radius | 5 m |
About the model
The Grove GMK5240 is an all-terrain crane by Grove with a maximum lifting capacity of 158.8 t.
Hook height 60 m, maximum radius 54.9 m.
Engine output 421 kW.
