Grove · Rough-terrain cranes
Grove RT870
Max. lifting capacity63.5 t
Max. radius33.5 m
Max. hook height38.1 m
Specifications
| Specification | Value |
|---|---|
| Lifting | |
| Max. lifting capacity | 63.5 t |
| Max. radius | 33.5 m |
| Max. hook height | 38.1 m |
| Speeds | |
| Travel speed | 40.1 km/h |
| Slewing speed | 2 rpm |
| Carrier and engine | |
| Engine | Cummins 6CTA 8.3L |
| Power | 191 kW |
| Dimensions and weight | |
| Length | 14,347 mm |
| Width | 3,341 mm |
| Height | 3,978 mm |
| Total crane weight | 48.6 t |
| Tail swing radius | 4.28 m |
About the model
The Grove RT870 is a rough-terrain crane by Grove with a maximum lifting capacity of 63.5 t.
Hook height 38.1 m, maximum radius 33.5 m.
Engine output 191 kW.
