Grove · Rough-terrain cranes
Grove RT9100
Max. lifting capacity90.7 t
Max. radius30.5 m
Max. hook height34.7 m
Specifications
| Specification | Value |
|---|---|
| Lifting | |
| Max. lifting capacity | 90.7 t |
| Max. radius | 30.5 m |
| Max. hook height | 34.7 m |
| Speeds | |
| Travel speed | 26.1 km/h |
| Slewing speed | 2 rpm |
| Carrier and engine | |
| Power | 186 kW |
| Dimensions and weight | |
| Length | 13,890 mm |
| Width | 3,761 mm |
| Height | 4,148 mm |
| Total crane weight | 61 t |
| Tail swing radius | 4.34 m |
About the model
The Grove RT9100 is a rough-terrain crane by Grove with a maximum lifting capacity of 90.7 t.
Hook height 34.7 m, maximum radius 30.5 m.
Engine output 186 kW.
