Grove · Truck cranes

Grove TD522

Max. lifting capacity20 t
Max. radius19.8 m
Max. hook height21.3 m

Specifications

Specifications Grove TD522
SpecificationValue
Lifting
Max. lifting capacity20 t
Max. radius19.8 m
Max. hook height21.3 m
Speeds
Travel speed90.3 km/h
Slewing speed3 rpm
Carrier and engine
Power168 kW
Dimensions and weight
Length10,860 mm
Width2,432 mm
Height3,569 mm
Total crane weight21.3 t
Tail swing radius2.98 m

Report a data error →

About the model

The Grove TD522 is a truck crane by Grove with a maximum lifting capacity of 20 t.

Hook height 21.3 m, maximum radius 19.8 m.

Engine output 168 kW.
