Grove · Truck cranes

Grove TM1275

Max. lifting capacity113.4 t
Max. radius36.6 m
Max. hook height43 m

Specifications

Specifications Grove TM1275
SpecificationValue
Lifting
Max. lifting capacity113.4 t
Max. radius36.6 m
Max. hook height43 m
Speeds
Travel speed67.9 km/h
Slewing speed1.9 rpm
Carrier and engine
Power302 kW
Dimensions and weight
Length16,331 mm
Width3,002 mm
Height4,011 mm
Total crane weight82.6 t
Tail swing radius4.95 m

Report a data error →

About the model

The Grove TM1275 is a truck crane by Grove with a maximum lifting capacity of 113.4 t.

Hook height 43 m, maximum radius 36.6 m.

Engine output 302 kW.
