Grove · Truck cranes

Grove TM650

Max. lifting capacity59 t
Max. radius35.1 m
Max. hook height36.3 m

Specifications

Specifications Grove TM650
SpecificationValue
Lifting
Max. lifting capacity59 t
Max. radius35.1 m
Max. hook height36.3 m
Speeds
Travel speed73.4 km/h
Slewing speed2.7 rpm
Carrier and engine
Power227 kW
Dimensions and weight
Length13,804 mm
Width3,252 mm
Height3,776 mm
Total crane weight40.7 t
Tail swing radius4.27 m

Report a data error →

About the model

The Grove TM650 is a truck crane by Grove with a maximum lifting capacity of 59 t.

Hook height 36.3 m, maximum radius 35.1 m.

Engine output 227 kW.
