Grove · Truck cranes

Grove TM9150

Max. lifting capacity136.1 t
Max. radius45.7 m
Max. hook height48.8 m

Specifications

Specifications Grove TM9150
SpecificationValue
Lifting
Max. lifting capacity136.1 t
Max. radius45.7 m
Max. hook height48.8 m
Speeds
Travel speed88.5 km/h
Slewing speed1.7 rpm
Carrier and engine
Power325 kW
Dimensions and weight
Length15,795 mm
Width3,341 mm
Height3,981 mm
Total crane weight81.9 t
Tail swing radius4.7 m

Report a data error →

About the model

The Grove TM9150 is a truck crane by Grove with a maximum lifting capacity of 136.1 t.

Hook height 48.8 m, maximum radius 45.7 m.

Engine output 325 kW.
