Grove · Truck cranes

Grove TMS800E

Max. lifting capacity66.7 t
Max. radius36.6 m
Max. hook height39 m

Specifications

Specifications Grove TMS800E
SpecificationValue
Lifting
Max. lifting capacity66.7 t
Max. radius36.6 m
Max. hook height39 m
Speeds
Travel speed104.1 km/h
Slewing speed1.7 rpm
Carrier and engine
Power298 kW
Dimensions and weight
Length15,182 mm
Width2,618 mm
Height3,429 mm
Total crane weight41.1 t
Tail swing radius4.5 m

Report a data error →

About the model

The Grove TMS800E is a truck crane by Grove with a maximum lifting capacity of 66.7 t.

Hook height 39 m, maximum radius 36.6 m.

Engine output 298 kW.
