Grove · Truck cranes

Grove TMS900E

Max. lifting capacity70.3 t
Max. radius39.6 m
Max. hook height43.2 m

Specifications

Specifications Grove TMS900E
SpecificationValue
Lifting
Max. lifting capacity70.3 t
Max. radius39.6 m
Max. hook height43.2 m
Speeds
Travel speed104.1 km/h
Slewing speed1.7 rpm
Carrier and engine
Power336 kW
Dimensions and weight
Length13,067 mm
Width2,579 mm
Height3,615 mm
Total crane weight36.3 t
Tail swing radius3.85 m

Report a data error →

About the model

The Grove TMS900E is a truck crane by Grove with a maximum lifting capacity of 70.3 t.

Hook height 43.2 m, maximum radius 39.6 m.

Engine output 336 kW.
