Liebherr · All-terrain cranes

Liebherr LTM 1060-3.1

Max. lifting capacity60 t
Max. radius48 m
Max. hook height63 m
Main boom length10.3–48 m

Specifications

Specifications Liebherr LTM 1060-3.1
SpecificationValue
Lifting
Max. lifting capacity60 t
Max. radius48 m
Max. hook height63 m
Hook height with jib63 m
Boom
Main boom length10.3–48 m
Fly jib length2.5–16 m
Speeds
Travel speed85 km/h
Carrier and engine
Axle configuration6×4×6
EngineLiebherr 6-cylinder Diesel
Power270 kW

Report a data error →

About the model

The Liebherr LTM 1060-3.1 is an all-terrain crane by Liebherr with a maximum lifting capacity of 60 t.

Main boom length 10.3–48 m, hook height 63 m, maximum radius 48 m.

6×4×6 drive, engine output 270 kW.
