Liebherr · Truck cranes
Liebherr LTM1100-4.1
Max. lifting capacity100 t
Max. radius48 m
Max. hook height52 m
Specifications
| Specification | Value |
|---|---|
| Lifting | |
| Max. lifting capacity | 100 t |
| Max. radius | 48 m |
| Max. hook height | 52 m |
| Speeds | |
| Travel speed | 75.1 km/h |
| Slewing speed | 1.8 rpm |
| Carrier and engine | |
| Power | 355 kW |
| Dimensions and weight | |
| Length | 13,052 mm |
| Width | 2,752 mm |
| Height | 3,950 mm |
| Tail swing radius | 4.1 m |
About the model
The Liebherr LTM1100-4.1 is a truck crane by Liebherr with a maximum lifting capacity of 100 t.
Hook height 52 m, maximum radius 48 m.
Engine output 355 kW.
