Sany · Truck cranes
SANY STC1000S
Max. lifting capacity100 t
Max. hook height77.5 m
Main boom length56 m
Specifications
| Specification | Value |
|---|---|
| Lifting | |
| Max. lifting capacity | 100 t |
| Load moment | 336.5 t·m |
| Max. hook height | 77.5 m |
| Hook height with jib | 77.5 m |
| Boom | |
| Main boom length | 56 m |
| Fly jib length | 21.5 m |
| Speeds | |
| Travel speed | 80 km/h |
| Carrier and engine | |
| Axle configuration | 8 x 4 x 8 |
| Power | 275 kW |
| Dimensions and weight | |
| Length | 14,050 mm |
| Width | 2,800 mm |
| Height | 4,000 mm |
About the model
The SANY STC1000S is a truck crane by Sany with a maximum lifting capacity of 100 t.
Main boom length 56 m, hook height 77.5 m.
8 x 4 x 8 drive, engine output 275 kW.
